Aluminium Trefoil Cable Cleat

For Three Cable Formation :

• Manufactured From Aluminium Alloy
• Suitable For LV/MV Cable Dia 24mm to 76mm in 36 different sizes.
• Suitable for use with all standard ladder and tray system
• Three Piece, Single Bolt Fixing Design
• Two Bolt Fixing Design Available on Request
• Finish : Epoxy Coated
• Rubber Linear Optionally Available
• Operating temperatures -60°c to +105°c

Category: Cable Cleats

Previous Product
Aluminium Trefoil Cable Cleat(SP)

Next Product
Aluminium Two Bolt Cable Cleat

Description

Description

* All Dimensions Are in mm

PART NO	CABLE DIAMETER		DIAMENTIONS (mm)
	A ( mm)		B	D	Single Bolt	Two Bolt
	MIN	MAX	B	D	C	E	F
ATFC 15-18	15	18	77	34	–	104	77
ATFC 18-22	18	22	85	34	–	116	87
ATFC 22-25	22	25	91	34	–	122	94
ATFC 24-25	24	25	97	37	85	126	101
ATFC 25-27	25	27	97	37	85	126	101
ATFC 27-28	27	28	97	37	85	130	104
ATFC 28-30	28	30	102	38	85	130	104
ATFC 30-32	30	32	105	38	85	133	107
ATFC 32-34	32	34	105	38	89	135	109
ATFC 34-35	34	35	112	38	96	198	113
ATFC 35-36	35	36	113	38	98	138	113
ATFC 36-38	36	38	116	38	98	140	114
ATFC 38-40	38	40	119	38	100	145	118
ATFC 40-41	40	41	122	38	108	147	121
ATFC 41-43	41	43	122	38	108	147	121
ATFC 43-44	43	44	127	38	108	152	126
ATFC 44-46	44	46	130	38	110	154	128
ATFC 46-48	46	48	133	38	116	157	130
ATFC 48-49	48	49	137	38	123	160	134
ATFC 49-51	49	51	140	38	119	165	136
ATFC 51-53	51	53	140	38	122	155	134
ATFC 53-54	53	54	145	38	129	172	141
ATFC 54-55.5	54	55.5	152	44	138	183	152
ATFC 55-57	55	57	155	44	138	187	155
ATFC 57-59	57	59	152	38	141	173	148
ATFC 59-60	59	60	165	44	148	195	162
ATFC 60-62	60	62	168	44	149	195	162
ATFC 62-63.5	62	63.5	170	44	156	202	168
ATFC 63.5-65	63.5	65	173	44	156	202	168
ATFC 65-66.5	65	66.5	173	44	156	202	168
ATFC 66.5-68	66.5	68	180	44	156	210	176
ATFC 68-70	68	70	180	44	158	210	176
ATFC 70-71.5	70	71.5	190	44	171	217	185
ATFC 71.5-73	71.5	73	190	44	171	217	185
ATFC 73-74.5	73	74.5	186	44	171	217	185
ATFC 74.5-76	74.5	76	189	44	166	220	186

* Confirming To IEC 61914
* Tolerance Applied+/-3%
